124 EDGE Pro Ti CNC Instruction Manual 807660
Maintenance and Diagnostics
4-axis MCC board (141191)
Table 24 Pinouts for J1 I/O 1 to 12
Table 25 J2 Axis 1 to 4
Pin no. Signal Pin no. Signal
1 Input 1 26 Not connected
2 Output 1 27 Not connected
3 Input 2 28 Not connected
4 Output 2 29 Not connected
5 Input 3 30 Not connected
6 Output 3 31 Not connected
7 Input 4 32 Not connected
8 Output 4 33 Not connected
9 Input 5 34 Not connected
10 Output 5 35 Not connected
11 Input 6 36 Not connected
12 Output 6 37 Not connected
13 Input 7 38 Not connected
14 Output 7 39 Not connected
15 Input 8 40 Not connected
16 Output 8 41 Not connected
17 Input 9 42 Not connected
18 Output 9 43 Not connected
19 Input 10 44 Not connected
20 Output 10 45 Not connected
21 Input 11 46 Not connected
22 Output 11 47 Picopath ID (0=True)
Hypath ID (NC=1=False)
23 Input 12 48 Not connected
24 Output 12 49 Not connected
25 Not connected 50 Ground
Pin no. Signal Pin no. Signal
1 /Axis 1 enable 21 Not connected
2 /Axis 2 enable 22 Not connected
3 /Axis 3 enable 23 Not connected
4 /Axis 4 enable 24 Not connected
5 Not connected 25 Not connected
6 Not connected 26 Ground
7 /Watchdog enable 27 Ground
8 Axis 1A 28 Analog common
9 Axis 1B 29 Axis 1 analog
10 Axis 1Z 30 Axis 2 analog
11 Axis 2A 31 Axis 3 analog
12 Axis 2B 32 Axis 4 analog
13 Axis 2Z 33 Not connected
14 Axis 3A 34 Not connected
