EDGE Pro Ti CNC Instruction Manual 807660 85
Installation
Plasma connection
Plasma connection to HSD130 plasma systems
The plasma interface cable and plasma interface assembly for HSD130 plasma systems are packaged together as a kit.
The Field Service Bulletin (805690) for the kit provides instructions for installing the plasma interface assembly and
connecting the plasma interface cable.
Figure 46 Plasma interface cable to an HSD130 plasma system
Figure 47 HSD130 plasma interface cable
Diameter = 7.213 mm (0.284 in.)
Bend radius = 150 mm (6 in.)
1
15
