EDGE Pro Ti CNC Instruction Manual 807660 27
Section 1
Specifications
Main features of an automated cutting system
The diagram in Figure 1 illustrates the relationship between the components of an automated cutting system.
The following sections describe these components and their relationships more fully.
Figure 1 Components of an automated cutting system
Operator console
Cutting table
Control box
Drive amplifier
Oxyfuel cutting
system
EDGE Pro
CNC
THC
Plasma system
Products available from Hypertherm
