146 EDGE Pro Ti CNC Instruction Manual 807660
EDGE Pro Ti Parts List
Safety circuit kits
Safety circuit kits
Diagnostic kits
Cables
Part Kit number Description
Safety relay 003239 Manages E-stop and reset logic
E-stop mushroom switch 428025 DPST normally closed, red/yellow, red LED
Reset push button switch 428026 Momentary, SPST normally open, green
Part Kit number Description
Comprehensive set of testers 428057 Includes all testers in this table
Communication testers Ethernet and Hypernet
Serial interface RS-232 or RS-422 on the utility and serial isolation
board
USB
I/O testers Green, for dry contact input mode
Red, for dry contact input mode
Orange, for sourced contact input mode
White, for sourced contact input mode
E-stop tester Blue, for dry contact input mode
Yellow, for sourced contact input mode
Lifter and plasma interface tester For lifter and plasma interface connections
Part Kit number Description
E-stop cable, terminated at the CNC
end only
223365 3.05 m (10 ft)
223366 6.08 m (20 ft)
223367 7.50 m (25 ft)
223368 10.66 m (35 ft)
223369 15.25 m (50 ft)
Plasma interface cable
for connection
to plasma systems with a compatible,
built-in voltage divider
223354 3.05 m (10 ft) for Powermax plasma systems
223355 6.08 m (20 ft) for Powermax plasma systems
223048 7.50 m (25 ft) for Powermax plasma systems
223356 10.66 m (35 ft) for Powermax plasma systems
123896 15.25 m (50 ft) for Powermax plasma systems
Plasma interface and cable
for
connection to HSD130 plasma
systems
428019 3.05 m (10 ft) for HSD 130 plasma systems
428020 6.08 m (20 ft) for HSD 130 plasma systems
228247 7.62 m (25 ft) for HSD 130 plasma systems
428021 10.66 m (35 ft) for HSD 130 plasma systems
228248 15.25 m (50 ft) for HSD 130 plasma systems
228306 22.86 m (75 ft) for HSD 130 plasma systems
Plasma interface cable
for connection
to plasma interface assembly 228256
223358 3.05 m (10 ft)
223359 6.08 m (20 ft)
223360 7.62 m (25 ft)
223361 10.66 m (35 ft)
228249 15.25 m (50 ft)
223363 22.86 m (75 ft)
