EDGE Pro Ti CNC Instruction Manual 807660 141
Maintenance and Diagnostics
4-axis DC servo board (141281)
Servo amplifier (228360)
Figure 71 Servo amplifier board
Top side of the servo
amplifier board
These pins attach
the amplifier to the
servo board
(141281)
