EDGE Pro Ti CNC Instruction Manual 807660 37
Section 2
Installation
Upon receipt
• Verify that all the system components on your order have been received. Contact your supplier if any
items are missing.
•EDGE Pro Ti CNC
• Power cable (North America)
• EDGE Pro Ti CNC instruction manual
• Phoenix software instruction manuals
• Any other optional components that appear on your order form
• Inspect the system components for any physical damage that may have occurred during shipping.
If there is evidence of damage, refer to the following section, Claims. All communications regarding
claims must include the model number and serial number located on the back of the CNC.
Claims
Claims for damage during shipment – If your unit was damaged during shipment, you must file a claim with the carrier.
Hypertherm will furnish you with a copy of the bill of lading upon request. If you need additional assistance, call Customer
Service listed in the front of this manual, or your authorized Hypertherm distributor.
Claims for defective or missing merchandise – If any of the merchandise is defective or missing, contact your supplier.
If you need additional assistance, call Customer Service listed in the front of this manual, or your authorized Hypertherm
distributor.
Installation requirements
All installation and service of electrical systems must conform to national and local electrical codes. This work should be
performed only by qualified personnel.
Gantry sizing for EDGE Pro Ti motors
There are many features of a cutting table that impact the performance of the complete system including:
• Size of the pinion gear
• Ratio of the gears
• Choice of direct-drive gearboxes or pulley sizing
• Gantry weight
