150 EDGE Pro Ti CNC Instruction Manual 807660
EDGE Pro Ti Parts List
Additional kits
Additional kits
Part Kit number Description
Servo bus power supply 428006
60 VDC, 1000 W
ATX power supply 228473 1 U, 300 W, with harness and bracket
Servo amplifier fan 428060 Installed under the shroud on the rear of the CNC
Side cooling fan 428007 Installed under right side and top shroud
Subchassis cooling fan 228474 Internal
CPU fan 428012 Internal
DC servo amplifier 428008 Installed on 4-axis servo board (see PCB kits)
Battery for motherboard 428011 3 V lithium, coin cell, CR2032-type
Fuse 208142 240 V, 10 A, slow-blow, 5 mm x 20 mm
Power entry module 428058 Includes internal harness and 2 fuses
Ribbon cable for utility and serial board 229245
Hasp hardware key 228446
Hard drive, SATA 228447 Includes Windows XPe operating system
15" LCD touchscreen 228462
Joy stick 228471
Speed potentiometer 228470
Stop switch assembly, red 228468
Start switch assembly, green 228467
Power switch 228465
Station select toggle switch 228469
White pushbutton switch assembly 228463
Hypernet/LAN RJ-45 connector 228445
