148 EDGE Pro Ti CNC Instruction Manual 807660
EDGE Pro Ti Parts List
Cable connector kits
Cable connector kits
PCB kits
Part Kit number Description
Cable connector kits (include housings,
backshells, pins, sockets)
228126 I/O cable connector (includes connectors for all 4 I/O
connections)
428045 Motor and encoder cable connectors. 1 kit is required for each axis.
428046 E-stop cable connector
428047 24 VDC auxiliary power cable connector
228493 Serial connector, DB 9, male. solder cup, with backshell
428059 Metal shell, panel mount USB connector with molded cable, metal
dust cover, and washer
Part Location Kit number Description
PCB kits
1
428002 I/O board (141278)
2
428003 4-axis servo board (141281)
3
428005 Surge and safety board (141287)
4
228450 Operator control panel board (141058)
5
428063 Wireless board (141223), includes 2 cables and antennas
6
428001 Utility and serial isolation board (141307)
7
428004 4-axis MCC board (141191)
8
228454 Motherboard (141110), with CPU, heatsink/fan, and RAM
9
228448 Power distribution board (141153)
