Page #33 background imageLoading...
Page #33 background image
EDGE Pro Ti CNC Instruction Manual 807660 33
Specifications
System specifications
System specifications
The following table contains technical specifications for the EDGE Pro Ti CNC.
Table 1 System specifications for the EDGE Pro Ti CNC
System features
Processor
Intel
®
Processor
Operating system Windows XPe
RAM ≥1GB
Ethernet port 1 RJ-45 Ethernet port
Hypernet port 1 Hypernet port for use with the ArcGlide THC
USB ports 2 USB 2.0 ports
Serial ports 2 RS-422/RS-232 configurable ports with D-sub 9-pin connectors
Wireless communication Complies with 802.11G and 802.11N standards.
Onboard monitoring devices Hardware monitoring, CPU fan, CPU temperature, voltages, POST display
Hard drive SATA drive
Operator console 2-station standard (expandable by table manufacturer)
Display 381 mm (15 in.) touchscreen, surface acoustic wave glass
Regulatory compliance CE, CSA, GOST-R
Configuration
Number of I/O 12/12
I/O Type Positive logic input or dry contact and relay output
Axes available 2 – 4
Power
AC input Voltage: 100 VAC to 240 VAC
Current: single-phase, 10.0 A at 100 VAC/4.1 A at 240 VAC
Frequency: 50/60 Hz
DC output Encoder power: 5 VDC
E-stop power: 24 VDC
Axis 4 brake power: 24 VDC at 500 mA
Total field power available: Encoders = 5 V/0.5A, I/O = 1.5 A, E-stop = 500 mA, lifter brake = 0.5 A
Slow blow fuse (2) 250 V, 10A, 5 mm x 20 mm
DC available for I/O 24 V at 1.5 A
Servo output 700 watts continuous at 120 VAC input
700 continuous watts and 1,000 intermittent watts at 70% duty at 240 VAC input
DC brush or brushless motors with Hall sensor feedback
