EDGE Pro Ti CNC Instruction Manual 807660 145
Section 5
EDGE Pro Ti Parts List
EDGE Pro Ti CNC parts
Sensor Ti THC parts
Interface assembly kits
Part Kit number Description
Motor
031143 Brushless motor (NEMA 34) for X and Y axes
Replacement Sensor Ti lifter 228209 Includes motor, encoder, (10 lb) magnetic breakaway
Replacement lifter motor with encoder 228189 70 V, with encoder, brake, and harness
Motor to ballscrew coupling 228207
Ohmic contact wire 228191
Magnetic breakaway assembly 228193 10 lb
Torch mounting block 128277 35 mm (1-3/8 in.)
128278 44 mm (1-3/4 in.)
128279 50 mm (2 in.)
Breakaway sensor and cable 228194 Terminated, includes fastener
Sensor Ti upper sheet metal cover 228195 Includes fasteners
Sensor Ti lower sheet metal cover 228196 Includes fasteners
Sensor Ti lifter silicone end stop 228197 Includes fastener
Ball screw 228198 4 mm pitch, with ball nut, top and bottom bearing blocks and
fasteners
Part Kit number Description
Plasma interface assembly 228256 Installed in plasma systems with no compatible, built-in voltage
divider
Plasma interface assembly for HSD130
plasma systems
See Cables for HSD plasma interface and cable kits
To Next Page
