EDGE Pro Ti CNC Instruction Manual 807660 153
Wiring Diagrams
Wiring diagram symbols
Section
Switch, pressure,
normally open
Time delay open,
NO/off
Valve, solenoid
Switch, 1 pole, 1 throw
Time delay open,
NC/on
Voltage source
Switch, 1 pole, 2 throw
Time delay closed,
NO/off
Zener diode
Switch, 1 pole, 2 throw,
center off
Transformer
Switch, temperature,
normally closed
Transformer, air core
Switch, temperature,
normally open
Transformer, coil
Terminal block Triac
Time delay closed,
NC/off
VAC source
Torch symbols
Electrode
Nozzle
Shield
Torch
Torch, HyDefinition™
