EDGE Pro Ti CNC Instruction Manual 807660 67

Installation

Motor connection

Table 11 Pinouts for the motor cable

Use the following information to order motor cables.

To create a custom cable, order the connector kit (428045).

Pin no. Wire color Signal

1 Red Phase A

2 Black Phase B

3 Red Phase C

4 Red Brake+

5 Black Brake-

6 Red Not connected

7 Black Chassis

8 Drain wire Shield

Part Number Length

223052 1.52 m (5 ft)

223051 3.05 m (10 ft)

223347 6.08 m (20 ft)

123972 7.62 m (25 ft)

123973 10.06 m (33 ft)

223348 10.66 m (35 ft)

123974 10.97 m (36 ft)

123902 15.25 m (50 ft)
