EDGE Pro Ti CNC Instruction Manual 807660 79
Installation
Plasma connection
Table 17 Pinouts for plasma interface cable
Use the following information to order this plasma interface cable.
End A signal Pin no. Wire color Pin no. End B signal
+12 V to Transfer + 1 to 4 Jumper, black
Start 2 Black 4 Start
Start 10 Red 3 Start
Transfer 12 Black 12 Transfer-
Transfer 5 White 14 Ground
V-Div- 15 Black 5 V-Div-
V-Div+ 8 Green 6 V-Div+
Ground Shell Drain wire 13 Shield
Part Number Length
223354 3.05 m (10 ft)
223355 6.08 m (20 ft)
223048 7.62 m (25 ft)
223356 10.66 m (35 ft)
123896 15.25 m (50 ft)
