Hypertherm Powermax 125 Service Manual

Powermax125 Service Manual 808070 241
9 – Power Supply Component Replacement
Install the output inductor
1. Place the output inductor in the power supply while guiding the long inductor wires through the opening in the
bottom of the center panel. See Figure 97 on page 242.
2. Insert the tabs on the front of the output inductor into the slots in the base of the power supply.
3. Push the electrode wire through the protective sheathing that passes through the center panel.
4. Tighten the 2 supplied mounting screws in the base of the output inductor to 69.1 kg-cm (60 inch-pounds).
5. Verify that the plastic washer is installed over the plastic hub on the rear of the quick disconnect receptacle.
6. Place the ring terminal over the silver-plated fitting and tighten the nut onto the fitting. Tighten the nut to 46.1 kg-cm
(40 inch-pounds), but do not overtighten – the plastic washer should be able to spin when the brass nut is installed.
7. Push the 90° push-to-connect fitting onto the silver-plated fitting until full seated.

Hypertherm Powermax 125 Specifications

General

Output Current	30-125 A
Input Power	15.2 kW
Open Circuit Voltage	300 VDC
Gas Supply	Clean, dry, oil-free air or nitrogen
Input Power Cable Length	10 ft (3 m)
Rated Output Current	125 A
Gas Type	Air or nitrogen
Cutting Capacity	1-1/4 inch (32 mm)
Pierce Capacity	1 inch (25 mm)
Input Voltage	200-600 V, 3-PH
Duty Cycle	100% @ 125 A
Certifications	CSA
Maximum Clean Cut Thickness	1-1/4 inch (32 mm)
Cooling Method	Fan-cooled
Torch Options	Hand
