IBM Infoprint 6500-v05 User Manual

470
11. Pull the paper tray out until the holes in the rails permit access to the M3 buttonhead screws. (Figure 67)
12. Loosen one turn—do not remove—the M3x6 screws securing the vertical rails to the stacker base. Each rail is secured by
two screws. (Figure 67.)
Figure 67. This figure shows how to loosen the lower screws in the vertical rails of the stacker.
M3x6 Buttonhead Screw
(Two on each rail)
Access Hole in
Tray Rail
