Chapter 11. SAN connections and configuration 489
zone name FSV7K_N11
pwwn 50:05:07:68:05:04:02:50
pwwn 50:05:07:68:05:04:02:51
pwwn 10:00:5c:f3:fc:6e:30:01
Router(config-zone)#zoneset name CN4093_1------------------------> Create Zoneset
Router(config-zoneset)#member FSV7K_N11---------------------> Add Zone to Zoneset
Router(config-zoneset)#show zoneset-------------------------------> Check Zoneset
zoneset name CN4093_1
zone name FSV7K_N11
pwwn 50:05:07:68:05:04:02:50
pwwn 50:05:07:68:05:04:02:51
pwwn 10:00:5c:f3:fc:6e:30:01
zoneset name FCOE_Zoneset1
Example 11-6 shows, from the ISCLI, activating the zoneset and then checking to ensure the
configuration and active zoneset are correct.
Example 11-6 Activating and checking zoneset
Router(config-zoneset)#zoneset activate name CN4093_1----------> Activate Zoneset
Router(config)#show zoneset active-----------------------------> Check Activation
Active Zoneset CN4093_1 has 1 zones
zoneset name CN4093_1
zone name FSV7K_N11
pwwn 50:05:07:68:05:04:02:50
pwwn 50:05:07:68:05:04:02:51
pwwn 10:00:5c:f3:fc:6e:30:01
Default-Zone Deny
Router(config)#
After this operation is successfully completed, the PWWN should be visible from IBM Flex
System V7000 Storage Node, where a host can be created and storage allocated.
Figure 11-34 shows that the PWWN from the FCoE attached Compute Node 11 is seen from
the administrative GUI of the IBM Flex System V7000 Storage Node. It can be used to define
a host and host port so that volumes can be assigned.
It is important to remember that this entire process has to be repeated on the IBM Flex
System CN4054 10Gb Virtual Fabric Adapter residing in I/O Module port 2 in the IBM Flex
System Enterprise Chassis where a second host port can be added to the host name. It will
eliminate one of the switches as being a point of failure. The same VLAN number must be
used; in the previous example, we used VLAN 1002.
