Appendix A. CLI setup and configuration 633
4. You are prompted for a name (for example, pubkey) and a location for the public key
(for example, C:\Support Utils\PuTTY). Click Save.
Ensure that you record the name and location, because the name and location of this SSH
public key must be specified later.
5. Click Save private key (Figure A-4).
Figure A-4 Save private key
6. You are prompted with a warning message (Figure A-5). Click Yes to save the private key
without a passphrase.
Figure A-5 Confirm the security warning
7. When prompted, enter a name (for example, “icat”), select a secure place as the location,
and click Save.
8. Close the PuTTY key generator.
Public key extension: By default, the PuTTY key generator saves the public key with
no extension. Use the string “pub” for naming the public key, for example, “pubkey”, to
easily differentiate the SSH public key from the SSH private key.
Key generator: The PuTTY key generator saves the private key with the PPK
extension.

IBM V7000 Specifications

General

Model	IBM Storwize V7000
Storage Type	Hybrid Flash Array
Maximum Capacity	1.2PB
RAID Levels	0, 1, 5, 6, 10
Connectivity	8 Gbps Fibre Channel, 16 Gbps Fibre Channel, 1 Gbps iSCSI, 10 Gbps iSCSI
Management	Command-line interface (CLI), Graphical user interface (GUI)
Form Factor	2U
Drive Bays	12
Maximum Raw Capacity	1.2PB
Operating System Support	AIX, HP-UX, Linux, VMware, Windows
Data Reduction Features	Real-time Compression, Deduplication
Drive Types	SSD, HDD
Scalability	Scale-up (drive enclosures) and scale-out (clustering) capabilities
