3 Analog I/O Modules
30-16 WindO/I-NV4 User’s Manual
Data Type
The analog input value can be handled as the set data type. There are seven data types for the analog inputs.
YES: Supported, NO: Not supported
*1 For only the FC6A-J8A1, binary data (12 bits) and optional range (12 bits) are displayed.
*2 Can only be set when the signal type is thermocouple, resistance thermometer or NTC thermistor.
*3 Resistance when using the FC6A-J8CU1 and the signal type is set to PTC thermistor or Resistance measurement.
*4 Binary data (16 bits) and optional range (16 bits) can be used with the following versions.
FC6A-J8A1: Hardware version 200 or later (Refer to “ Checking the Hardware Version Number” on page 30-4.)
If a FC6A-J8A1 that does not correspond to the above version numbers is set to binary data (16 bits) or optional range (16
bits), an error will occur and the module will operate as binary data (12 bits).
Data Type
FC6A-
J2C1
FC6A-
J4A1
FC6A-
J8A1
FC6A-
J4CN1
FC6A-
J4CH1Y
FC6A-
J8CU1
FC6A-
L06A1
FC6A-
L03CN1
Binary data
*1
YESYESYESYESYESYESYESYES
Optional range
*1
YESYESYESYESYESYESYESYES
Celsius
*2
NO NO NO YES YES YES NO YES
Fahrenheit
*2
NO NO NO YES YES YES NO YES
Resistance
*3
NO NO NO NO NO YES NO NO
Binary data
(16 bits)
NO NO
YES
*4
NO NO NO NO NO
Optional range
(16 bits)
NO NO
YES
*4
NO NO NO NO NO
