IDTECK iTDC - The Relation between Input and Output (3 Door Set-Up: EIO88 Extension I;O Board Default)

APPENDIX
iTDC
p.119
[15] EIO88 Input #8 00 00 00 00 00 00 00
[16] DURESS MODE 1 03 00 00 00 00 00 00
[17] DURESS MODE 2 03 00 00 00 00 00 00
[18] DURESS MODE 3 00 00 03 00 00 00 00
[19] DURESS MODE 4 00 00 03 00 00 00 00
[20] OUTPUT Time Schedule 00 00 00 00 00 00 00
[21] INPUT Time Schedule 00 00 00 00 00 00 00
[22] INPUT Type 01 01 01 01 01 01 01
[23] DR TIME OUT 1 00 00 00 00 00 00 00
[24] DR TIME OUT 2 00 00 00 00 00 00 00
[25] DR TIME OUT 3 00 00 00 00 00 00 00
[26] DR TIME OUT 4 00 00 00 00 00 00 00
Index No Relay#1 Relay#2 Relay#3 Relay#4 TTL#1 TTL#2 TTL#3
Default output values of EIO88 Relay#1 ~ Relay#8 are all “00”.
INPUT Type: “00”= NC, “01”= NO
DR TIME OUT 1~4 (Door Time Out 1~4): It is interval time between door opening and closing
when door opening time is over.
1.3 The relation between input and output (3Door set-up: EIO88 extension I/O
board default)
Index No Relay#
1
Relay#
2
Relay#
3
Relay#
4
Relay#
5
Relay#
6
Relay#
7
Relay#
8
[1] Input #1 (Door1 Exit
button)
00 00 00 00 00 00 00 00
[2] Input #2 (Door1 Contact
SW)
00 00 00 00 00 00 00 00
[3] Input #3 00 00 00 00 00 00 00 00
[4] Input #4 00 00 00 00 00 00 00 00
[5] Input #5 00 00 00 00 00 00 00 00
[6] Input #6 00 00 00 00 00 00 00 00
[7] Input #7 00 00 00 00 00 00 00 00
[8] EIO88 Input #1 (Door2
Exit)
03 00 00 00 00 00 00 00
[9] EIO88 Input #2 (Door2 00 03 00 00 00 00 00 00
