p.14
FEATURES
iTDC
4 SPECIFICATION
Model iTDC iTDC-SR
CPU
8bit Microprocessor
Memory Program Memory
64K Byte ROM
Data Memory
512K Byte Flash Memory
Users
Users and Event Buffers Defined Available
1,000 ~ 20,000 / 30,000 / 40,000 / 50,000 Users
Event Buffer
29,500~20,000 / 15,000 / 10,000 / 5,000 Events
Power / Current
DC 12V, Max.500mA
Reader Port
4ea (26bit Wiegand,
4 / 8bit Burst)
4ea (34bit Wiegand,
4 / 8bit Burst)
Communication
RS232 / RS422/ RS485(Max. 32ch)
TCP/IP (internal TCP/IP Module Required (IIM100 - Optional)
Baud Rate
9,600bps (Default) /
4,800bps, 19,200bps, 38,400bps (Selectable)
Input Port
7ea
Output Port
4ea (FORM-C Relay Output (COM, NO, NC) /
DC12V~18V, Rating Max 2A)
3ea (TTL Output / DC5V, Rating Max 20mA)
LED Indicator / Beeper
21 LED Indicators / Piezo Buzzer
Operating Temperature
0 ~ +65C (+32 ~ +149F)
Operating Humidity
10% ~ 90% Relative Humidity Non-Condensing
Dimension ( W x H x T)
5.7”x7.3”x0.7” (145mm x 185mm x 18mm)
Weight (EIO88 Included)
375g (0.82lbs)
Certification
FCC, CE, KC, RoHS, UL
In/Output Expansion Board (EIO88) ( To control 3~4 doors)
Reader / Input / Output Port
8ea Input Port, 8ea Output Port
Optional (Manual Setting available for Standalone Operation)
LCD
Character LCD (2 Lines x 16 Char) /
80mm x 36mm(3.15”x1.41”) Screen
Keypad
16key Keypad / Membrane
