p.36
PRODUCT INSTALLATION
iTDC
Must check if power is off when you wire. If power is on when you wire, you get an
electric shock.
5 POWER WIRING
●
Connect (+) wire (Red) of DC 12V power to +12V terminal of iTDC/iTDC-SR Mainboard
power port.
●
Connect GND wire (Black) of DC 12V power to GND terminal of iTDC/iTDC-SR
Mainboard power port.
