IDTECK iTDC - Expansion I;O Board (Eio88) Port

PRODUCT INSTALLATION
iTDC
p.31
No. Name
1 Power Port
2 RS422 Communication Port
3 RS232 Communication Port
4 TTL Output (#1 ~ #3) Port
5 Relay Output(#1 ~ #4) Port
6 Board ID Setting Switch
7 Input(#1 ~ #7) Port
8 Reader(#1 ~ #4) Port
2 EXPANSION I/O BOARD (EIO88) PORT
No. Name
1 Input (#1 ~ #4) Port
2 Output(#1 ~ #4) Port
3 Input(#5 ~ #8) Port
4 Output(#5 ~ #8) Port
