p.126
APPENDIX
iTDC
But, two functions (1 & 2) cannot be used at the same time.
1.9 Default values on the outputs regarding access attempts (4Door set-up: iTDC
board default)
Index No Relay#1 Relay#2 Relay#3 Relay#4 TTL#1 TTL#2 TTL#3
[1] Reader#1 ID OK 03 00 00 00 00 00 00
[2] Reader#1 ID Error 00 03 00 00 00 00 00
[3] Reader#1 ID T/S Error 00 03 00 00 00 00 00
[4] Reader#1 APB Error 00 03 00 00 00 00 00
[5] Reader#2 ID OK 00 00 03 00 00 00 00
[6] Reader#2 ID Error 00 00 00 03 00 00 00
[7] Reader#2 ID T/S Error 00 00 00 03 00 00 00
[8] Reader#2 APB Error 00 00 00 03 00 00 00
[9] Reader#3 ID OK 00 00 00 00 00 00 00
[10] Reader#3 ID Error 00 00 00 00 00 00 00
[11] Reader#3 ID T/S Error 00 00 00 00 00 00 00
[12] Reader#3 APB Error 00 00 00 00 00 00 00
[13] Reader#4 ID OK 00 00 00 00 00 00 00
[14] Reader#4 ID Error 00 00 00 00 00 00 00
[15] Reader#4 ID T/S Error 00 00 00 00 00 00 00
[16] Reader#4 APB Error 00 00 00 00 00 00 00
[17] R1 SPECIAL ID 00 00 00 00 00 00 00
[18] R2 SPECIAL ID 00 00 00 00 00 00 00
[19] R3 SPECIAL ID 00 00 00 00 00 00 00
[20] R4 SPECIAL ID 00 00 00 00 00 00 00
Default values of the EIO88 Expansion I/O board are all ‘00’s.
※ R1 SPECIAL ID ~ R4 SPECIAL ID:
1. When you use arm/disarm function, this index sets output time.
2. When you use 2 levels individual door opening time function, this index sets door
opening time by doors.
But, two functions (1 & 2) cannot be used at the same time.
