p.26
PREPARATION OF INSTALLATION
iTDC
8 conductor, shielded
4 Door Lock, Alarm Device
Lock (Alarm) ↔ iTDC/iTDC-SR
Belden #9409, 18AWG
2 conductor, unshielded
300m
5 RS232 Cable
Converter ↔ Host P.C.
Belden #9829, 24 AWG
2-twisted pair, shielded
15m
6 RS485 Cable
iTDC/iTDC-SR ↔ iTDC/iTDC-SR
iTDC/iTDC-SR ↔ Converter
Belden #9829, 24 AWG
2-twisted pair, shielded
1,200m
RS422 Cable
iTDC/iTDC-SR ↔ iTDC/iTDC-SR
iTDC/iTDC-SR ↔ Converter
Belden #9830, 24 AWG
3-twisted pair, shielded
7 UTP Cable
Host PC ↔ HUB
HUB ↔ iTDC/iTDC-SR
UTP Cable CAT5(Catagory5) 100m
Reference Description Cable Specification Maximum
Distance
For Reader of reference 2, you have to use wire that thick enough to bear higher
current than maximum consuming current.
3 HOW TO EQUIP OPTIONAL SPECIFICATION
You must connect LCD module on none power status otherwise the LCD module
may has trouble to operate.
3.1 EQUIPMENT OF TCP/IP MODULE (IIM100)
Please check to correct direction to equip optional TCP/IP module (IIM100). See figure below.
