p.34
PRODUCT INSTALLATION
iTDC
No. / Name How to connect Earth GND
1. Nema case The Nema case IDTECK offers is metal Nema Case but if you are used other
nema case, metal Nema Case must be used.
2. Supporter All supporters (Supporter to connect iTDC/iTDC-SR main board to EIO88,
Supporter to connect Nema case to iTDC/iTDC-SR and Supporter to connect
Nema case to power supply device) to connect in Nema case have to be
