Setup Manual Page 123
D.6.1.7 Laser Check
This function checks the integrity and position of the laser line. The function will return
skew and relative position to its ideal values and is used to track potential misalignment.
The laser line is used by the camera electronics to measure the documents contour and
to calculate the correction for the curvature of the document binding.
Picture 104: Laser Check screen
Close the book cradles and place the Laser Check test target as displayed on the screen.
In the middle of each long side, the test target has a marking. Place the test target on the
book cradles so that the vertical laser line covers these markings.
Click on Next Step to start the measurement.
While the test sequence runs, the lamps will not light up. When the function has finished,
the screen shows the result. As long as the displayed text is green, the result is ok. Any
error will be shown in red followed by some explanatory remarks.
Picture 105: Laser Check result
