Setup Manual Page 131
D.6.3 Scan Test Targets
For system analysis and troubleshooting, it is useful to have an image of the CSTT test
target available.
The CSTT test target can be scanned in three different focus modes.
A button is available for each focus mode.
Picture 118: Focus modes for test scans
Select the desired focus mode for the test scan.
The following screen shows how to place the CSTT test target on the book cradles.
Picture 119: Placing the CSTT test target
Next Step starts the scan sequence.
