D.4.1.5 Foot Pedal
Use the function Foot Pedal to define an action for the foot pedals.
Picture 30: Foot pedal settings
The scanner has two connectors on its back to connect foot pedals.
Click below the symbols and select from the drop-down lists which action should be
executed when a pedal is operated.
Picture 31: Functions for the foot pedal
Drop-down list item
Function
Start scan
Starts the scan with the selected scan area size.
Start scan left page
Starts the scan and displays the left page of the
selected scan area size.
Start scan right page
Starts the scan and displays the right page of the
selected scan area size.
