EXPLANATION OF SYMBOLS ON LABELS

SYMBOL

DESCRIPTION

Manufacturer

Date of Manufacture

Consult instructions for use.

Caution, consult

accompanying documents

Transport Temperature

Limits

Sterilized with Ethylene

Oxide

Use By

Do Not Reuse

Part Number

Lot Number

Serial Number

Open Here

Torque Wrench

Port Plug

Do Not Use if Package is

Damaged

Class II

Type BF Applied Part
