• For enabling/disabling parameters (such as CCM Channels), checkboxes
are used, and a symbol indicates that the option is selected. To change
the option, select the box to the left of the parameter name.
• For parameters that have a set of possible values, the parameter value is
displayed in a box. In order to modify the (programmer) value of such
parameters, select the value in the box and a window with all the possible
values for the selected parameter will appear. To modify the value of the
parameter, select the new value in the list. In addition, the value list
windows have a “pin” on their top left corner. Selecting this pin keeps the
window open (otherwise, the window will close automatically after a
value is selected). Selecting the X box at the top right corner to close a
value list window that has the pin activated.
Some parameters directly depend on others (such as rates and periods). In such
cases, modifying the value of a parameter will automatically modify the value of
parameters that directly depend on it.
There also are parameters for which values are valid only when some other
parameters are enabled or have certain values [for instance, if the operating mode
of the OPTIMIZER Smart IPG is set to Standby (OOO), then no parameters are
valid]. When the setting of a parameter is meaningless in the context of other
parameters, its value is not displayed.
When a parameter value is selected that is incompatible with other parameter
values, a parameter conflict occurs. When such situations arise, an error message
is displayed in the Parameter Conflict Bar (See Section 12.9 for more
information). As long as there is a parameter conflict, the OMNI Smart
Programmer will not allow the OPTIMIZER Smart IPG to be programmed with
new parameter values. This ensures that only compatible parameter configurations
can be downloaded to the OPTIMIZER Smart IPG. To resolve the conflict, new
values must be selected for the parameters in conflict.
Please recall that parameter values seen on the screen are the programmer values,
which can be different from the current device values. For information on the
color convention employed, see Section 14.1.
12.10.3 Statistics
The Statistics Bar contains the following tabs, each with their own panel:
• On - General: displays the number of sensed events, periods, and trains
during scheduled CCM delivery.
• On - Inhibition: displays the number of sensed events that inhibited CCM
during scheduled CCM delivery.
• Off - General: displays the number of sensed events and periods when
CCM is not scheduled for delivery.
• Off - Inhibition: displays the number of sensed events that would have
inhibited CCM when CCM is not scheduled for delivery.
• Last Session: displays the number of ventricular events and trains
delivered during the last scheduled CCM delivery session, the percentage
