16.1 Opening a Standard File
To open a standard (.tip) file, perform one of the following actions:
• Select the Open button on the Tool Bar, or
• Press the keyboard shortcut <Ctrl+O>
• An Open window will pop up containing the names and locations of the standard
files that can be loaded. Choose a standard file and then click Open.
When parameter values are loaded from a standard file, these become the current
parameter values displayed by the Programmer. This implies that:
• If an OPTIMIZER Smart IPG has been interrogated before opening a standard
file, the values of the standard that are different from the corresponding parameter
values of the device will be displayed in blue and the name of the standard file
appears in the Title Bar.
• If no device has been interrogated, the values of the standard are displayed in
black, and the name of the standard file appears in the Title Bar.
16.2 Saving a Standard File
To save a parameter value set in a standard (.tip) file:
• Select the Save button on the Tool Bar
• A Save As window will pop up. Enter the file name of the standard to be saved
and then click Save.
17. LOADING AND EXPORTING INFORMATION
17.1 Loading Log Files
To load a Log file:
• Select the Log Files button on the Task Bar
• Select the Open Log button on the Tool Bar
• An Open window will pop up containing the names of the marker files that can
be loaded. Choose a marker file and then click Open.
A Marker window will open up and the color of the text in the Log Window will become
blue to indicate that the log does not correspond to the interrogated device.
17.2 Exporting Data
To save current parameter values, statistics counters, and log bar markers as text files:
• Select the Log Files button on the Task Bar
• Select the Export Prog button on the Tool Bar to export the parameter values.
• Select the Export Stats button on the Tool Bar to export the device statistics.
• Select the Export Marker button on the Tool Bar to export the contents of the
log bar.
