105
CCM TRAIN PARAMETERS
Parameters Name
Values
CCM Mode
CCM OFF
No pulse train enabled
Timed
As defined by the parameter values programmed
under the CCM Scheduling Tab.
Continuous
The pulse train is enabled for the entire day.
Number of Pulses
1, 2, or 3
CCM Train Delay
Between 3 ms and 140 ms in 1 ms increments
CCM Pulse Amplitude
Between 4.0 V and 7.5 V in 0.5 V increments
CCM Delivery Channels
LS and/or V
Phase 1 Duration
4 possible between 5.14 ms and 6.60 ms.
Phase 1 Polarity
“Positive” or “Negative”.
CCM INHIBIT PARAMETERS
Parameter Name
Values
Count
Between 1 and 16 in increments of 1
Short AV
1
49 possible between 23 ms and 398 ms
Long AV
1
49 possible between 23 ms and 398 ms
Atrial Tachycardia Rate
1
51 possible between 62 bpm and 179 bpm
Ventricular Tachycardia Rate
2
19 possible between 62 bpm and 110 bpm
1
: Active only when the OPTIMIZER Smart IPG is in Active ODO-LS-CCM mode.
2
: Active only when the OPTIMIZER Smart IPG is in Active OVO-LS-CCM mode.
LOCAL SENSE PARAMETER
Parameter Name
Values
Local Sense Sensitivity
18 possible between 0.1 mV to 10.0 mV
Local Sense Alert Start
Between –100 ms to 100 ms in 2 ms increments
Local Sense Alert Width
Between 1 ms to 40 ms in 1 ms increments
Local Sense Pre-Atrial refractory
period
1
Between 0 ms to 55 ms in 5 ms increments
Local Sense Post-Atrial refractory
period
1
Between 0 ms to 55 ms in 5 ms increments
Local Sense Pre-Ventricular refractory
period
Between 0 ms to 55 ms in 5 ms increments
Local Sense Post-Ventricular refractory
period
Between 0 ms to 39 ms in 1 ms increments
Local Sense Post-LS refractory period
Between 15 ms to 250 ms in 1 ms increments
1
: Active only when the OPTIMIZER Smart IPG is in Active ODO-LS-CCM mode.
