● [1.1] [Thru] [Enter] will select all fixtures and instances following fixture 1 instance 1 until a
different fixture type starts, or a gap in the numbering scheme is detected
● [1.1] [+] [1.2] [Enter] will select instance 1 and 2 of fixture 1
● [1.2] [+] [3.4] [Enter] will select instance 2 of fixture 1 and instance 4 of fixture 3
● [1.1] [Thru] [1.5] [Enter] will select all instances 1 thru 5 from fixture 1
● [1.1] [Thru] [1.10] [–] [1.3] [Enter] will select instances 1 to 10 except instance 3 of
fixture 1.
Repeatedly pressing [Prev] or [Next] while pressing the [Infinity] key steps backwards or forwards
through the instances in the current selection, with the order determined by the Selection Order.
[Prev] [+] [Next] will bring you back to your original selection.
Selecting specific Instances of the current selection using the Numberblock
To select specific fixture instances from fixtures that are currently selected on the keypad, simply do so by
typing their user the instance ID preceeded by [.].
You may use the [Thru], [+] and [-] keys to further extend your selection.
A few examples:
● [.1] [Thru] [Enter] will select all instances following instance 1 from within the current selection
● [.1] [+] [.2] [Enter] will select instance 1 and 2 of all fixtures within the current selection
● [.1] [Thru] [.5] [Enter] will select instances 1 thru 5 from fixtures the current selection
● [.1] [Thru] [.10] [–] [.3] [Enter] will select instances 1 to 10 except instance 3 of all
fixtures within the current selection.
