Infinity Chimp 300 - Selecting and Deselecting Groups; Selecting Fixture Groups Using Group Split Widget; Selecting Fixture Groups Using Command Line Interface; Naming Groups

114
Infinity Chimp Series
Infinity Chimp Series
Selecting and Deselecting Groups
Selecting Fixture Groups Using Group Split Widget
● Open a Group Pool Split widget by selecting Groups from a split widgets side menu.
● Now you can simply select and deselect fixture groups by clicking on them.
Selecting Fixture Groups Using Command Line Interface
● Press the [Group] key.
● Type the number of the group you would like to select via the console’s keypad such as [1]
followed by [Enter]. Please note that you may also use the [+], [-] and [Thru] keys to further
extend your selection.
So, for example:
[Group] [1] [+] [12] will select group 1 and 12.
[Group] [1] [Thru] [4] [-] [2] will select group 1 through 4 but will not select group 2.
Naming Groups
Assign Name using the Group Split Widget
● Select Groups from a split widgets side menu.
● Press the [Name] key.
● Select the group you wish to rename.
Assign Name using the Command Line Interface
● Press the [Name] key.
● Then press the [Group] key, followed by the Group ID, in this case [1].
● Hit [Enter] to complete the command.
Please note you may also rename multiple Groups at once by using the [Thru], [+] and [-] modifier
keys.
Assign Name using the Edit Group Window
You may also assign a Name to the group and its contained fixtures using the “Edit Group” Window.
Copying Groups
Copying Groups using the Group Split Widget
● Select Groups from a split widgets side menu.
● Press the [Copy] key.
● Select the Group you would like to copy
● Select the destination Item.
Copying Groups using the Command Line Interface
● Press the [Copy] key.
● Hit the [Group] key
● Enter the source Group ID, in this case [1]
● Now enter the desitnation Group ID, ie [5]
● Hit [Enter] to complete the command.
