Encoder Labels
The “Encoder Labels” show encoder function and values.
Clicking on the labels or pushing the encoder either shows the “select slots / keypad” dialog or toggles
between a set of commonly used values. In the programmer screen, labels will not show values. Instead,
the programmer window is used to display values.
Fig. 20: Encoder Labels
