IS810N-INT Series Servo System User Manual (Brief) Chapter 3 Installation
- 72 -
Motor model LB S TP LK KH KW W T Weight (kg)
ISMH1-10B30CB-***Z
30 8 M3×6 16 6.2
0
-0.1
3 3 3 0.59 (0.77)
ISMH1-20B30CB-****Z
50 14 M5×8 16.5 11
0
-0.1
5 5 5 1.1 (1.4)
ISMH1-40B30CB-****Z
50 14 M5×8 16.5
11
0
-0.1
5 5 5 1.6
ISMH1-55B30CB-****Z
70 19 M6×20 25 15.5
0
-0.1
6 6 6 2.3
ISMH1-75B30CB-****Z
70 19 M6×20 25 15.5
0
-0.1
6 6 6 2.7
ISMH1-10C30CB-****Z
70 19 M6×20 25 15.5
0
-0.1
6 6 6 3.2
Note: The dimension unit is mm. The values shown in () are values of servo motor with a
holding brake.
Connector Model
Power Side (Power Brake
Side Included)
Encoder Side
Plastic housing MOLEX-50361672 AMP172169-9
Terminal MOLEX-39000059 AMP1473226-1
2) Overall Dimensions of the ISMH2 Servo Motor Series (1.0 kW, 1.5 kW, 2.0 kW, 2.5 kW,
3.0 kW, 4.0 kW, 5.0 kW)
KB2
KB1
KA1
KA2
LZ
φLA
TP
LC
LL
LG
LE
LR
KW N9 W h8
T h11
KH
0.10 A
LJ
φS
h6
φLB
h7
0.03
A
LK
Φ0.06
A
Shaft end dimensions Keyed shaft end dimensions
