SECTION

CUSA Excel Ultrasonic Surgical Aspirator System User’s Guide 10-1

10Sterilizing Handpieces and

Accessories

In this section:

• Sterilization parameters

• Sterilize the handpiece.

For Your Information

After preparing the handpiece, sterilize it using steam.

After steam sterilization, the handpiece cable may appear collapsed. This

is normal. The cable regains its shape in about one hour. This does not

affect the handpiece performance or safety.
