SECTION

CUSA Excel Ultrasonic Surgical Aspirator System User’s Guide 11-1

11Completing Handpiece Setup

on the Sterile Field

In this section:

• Quick reference – setup

• Complete the handpiece assembly.

For Your Information

This section describes how to complete the handpiece setup on the sterile

field. It begins with the arrival of the sterilized handpiece and accessories

in the operating room. It ends with the handpiece ready to be connected

to the console.
