Console Body – Rear Panel
Console Components
CUSA Excel Ultrasonic Surgical Aspirator System User’s Guide 3-15
AC Power Cord
Connects power to the system from the wall receptacle.
Equipotential Grounding Lug
If you are using a CEM generator, the grounding lug allows you to
connect ground from the CEM generator to the CUSA EXcel console. This
is a biomedical function.
Labels
The labels show the console serial number and agency approvals.
Cord Wrap
The unit has two cord wraps. These are brackets that allow you to hang a
coil of cord on the back of the unit, keeping the cord safely out of the way.
Storage Compartment
This area, which includes one interior shelf, allows you to store a
footswitch and a manual.
