Configurations

Introduction to Handpieces

CUSA Excel Ultrasonic Surgical Aspirator System User’s Guide 7-3

Configurations

Three handpiece configurations are available:

• 36 kHz, straight (smaller handpiece, black body, blue connector)

• 23 kHz, straight (gray body, green connector)

• 23 kHz, angled (gray body, green connector).

Wide Variety of Tips

You can use a wide variety of tips with the CUSA EXcel handpieces. Tips

vary in inside and outside diameter, length, and shape (straight or

curved). For complete information on the tips that are available for each

handpiece, contact your Integra representative.

36 kHz

Straight

23 kHz

Straight

23 kHz

Angled
