CUSA Excel Ultrasonic Surgical Aspirator System User’s Guide xv
List of Figures
Figure 5-1. The assembled suction system 5-12
Figure 5-2. The assembled irrigation system 5-14
Figure 8-1. The components of a handpiece 8-2
Figure 8-2. The tip torquing base and torque wrench for use when not changing
tips on the sterile field
8-6
Figure 8-3. The sterilizable torque bases for use when changing tips on the
sterile field
8-7
Figure 8-4. The sterile torque wrench for use when changing tips on the sterile
field
8-8
Figure 8-5. The 23 kHz CUSA Excel sterilizer case 8-9
Figure 9-1. The items you need to assemble a handpiece: handpiece, nosecone,
and tip pack
9-2
Figure 9-2. Tip torquing base and torque wrench 9-3
Figure 9-3. Manifold tubing 9-3
Figure 9-4. The sterilizer case 9-8
Figure 9-5. The handpiece and connector secured into the sterilizer tray 9-9
Figure 14-1. Replacing o-rings on the handpiece connector water prongs 14-3
Figure 1. The sterilized handpiece S-2
Figure 2. The sterilized standard nosecone and the sterile CEM nosecones S-2
Figure 3. Sterile tip/flue pack contents. The tip cleaner is inside the flue. S-3
Figure 4. Sterilizable tip torquing base S-4
Figure 5. Sterile torque wrench (23 kHz or 36 kHz) S-4
Figure 6. Sterile manifold tubing S-4
Figure 7. The handpiece and connector secured into the sterilizer tray S-17
