Handpieces

Technical Specifications

CUSA Excel Ultrasonic Surgical Aspirator System User’s Guide A-7

Handpieces

Nominal Frequencies

Dimensions

23 kHz Straight

23 kHz Angled

36 kHz Straight

Tip Specifications

The table on pages A8 shows specifications for tips that attach to the

23 kHz handpiece.

The table on pages A9 shows specifications for tips that attach to the

36 kHz handpiece.

23 kHz Straight

23 kHz

23 kHz Angled

23 kHz

36 kHz Straight

35.75 kHz

Length

22.2 cm (8.74 in.)

Diameter

20.8 mm (0.82 in.)

Length

22.2 cm (8.74 in.)

Diameter

20.8 mm (0.82 in.)

Length

13.9 cm (5.47 in.)

Diameter

16.4 mm (0.65 in.)
