SECTION

CUSA Excel Ultrasonic Surgical Aspirator System User’s Guide 8-1

8Handpiece Components

In this section:

• Components of assembled handpieces

• Additional components.

For Your Information

This section presents the items that compose an assembled handpiece. It

describes the physical characteristics and function of each item.

This section also presents items that, although not a part of the handpiece

itself, are essential in assembling a handpiece or preparing it for

sterilization.
