Complete the Handpiece Assembly

Completing Handpiece Setup

on the Sterile Field

CUSA Excel Ultrasonic Surgical Aspirator System User’s Guide 11-7

4. Connect the manifold irrigation tubing to the Luer fitting on the

handpiece flue:

a. Connect the Luer

fitting.

b. Twist the knob

clockwise to lock the

fitting.
