Disassembly to Change Tips on the Sterile Field

Supplement: CUSA Excel Ultrasonic Surgical Aspirator System User’s Guide S-11

1. Press the Status button to

put the system in

Standby.

Disconnect the Manifold Tubing

1. Disconnect the irrigation tubing from the handpiece flue.

Status button
