Console Body – Rear Panel

3-12 CUSA Excel Ultrasonic Surgical Aspirator System User’s Guide

Console Body – Rear Panel

Fuses (2)

AC Main Switch

Footswitch

Volume Control

Footswitch Connector

Receptacle

Speaker
