Console Subsystems

A-2 CUSA Excel Ultrasonic Surgical Aspirator System User’s Guide

Console Subsystems

Ultrasonic

Fluidic System

Nominal Frequency

23 kHz

35.75 kHz

Maximum Tip Amplitude

(23 kHz)

Up to 355 microns for straight handpiece

Up to 183 microns for angled handpiece

Maximum Tip Amplitude

(36 kHz)

Up to 210 microns

Cooling System

Cooling water flow is 35 – 50 cc/min.

Irrigation Rate

The irrigation rate display shows digits 1 – 10

The irrigation rate is approximately

1 – 10 cc/min., normal; 25 – 30 cc/min., Fast

Flush

Suction System

Up to 660 mm (26 inches) mercury at the pump

intake at sea level

The suction level will be lower at higher

altitudes.
