Assembly
S-8 Supplement: CUSA Excel Ultrasonic Surgical Aspirator System User’s Guide
5. Align the dot on the
nosecone with the dot on
the neck of the
handpiece.
6. Push the nosecone onto
the handpiece so that the
dots are on top of each
other.
7. Twist the nosecone
clockwise until it locks
into place.
The dot on the nosecone
must now align with the
dot on the handpiece.
8. Remove the tip cleaner from the flue and set it aside. You may need it
during the surgical procedure to remove tissue blockage from the tip,
the suction connection to the handpiece, or both.
9. Slide the flue that
corresponds to the
selected tip over the tip
and onto the nosecone.
Markings on the flue indicate the tip the flue should cover:
Make sure to push the flue base completely over the nosecone base,
and that the end of the flue lines up with the pre-aspiration holes.
S Standard Tip
Mi MicroTip
Mit Micro TIp Plus
P PrecisionTip
Ma MacroTip
