SECTION

CUSA Excel Ultrasonic Surgical Aspirator System User’s Guide 14-1

14Maintaining the CUSA EXcel System

In this section:

• Quick reference

• Clean the sterilizer case

• Maintain the handpiece

• Store the CUSA EXcel system and accessories

• Return equipment for service

• Integra service centers.

For Your Information

Routinely performing a few simple maintenance tasks keeps your

CUSA EXcel system and handpieces operating at maximum safety and

performance. Biomedical Engineering at your facility should perform

these tasks.
