Console Body – Rear Panel

3-14 CUSA Excel Ultrasonic Surgical Aspirator System User’s Guide

Serial Number Label and

Agency Approval Labels

Equipotential

Grounding Lug

AC Power Cord

Storage Compartment

Cord Wrap
